PVC Lightweight Rigid Crust Foam Board Extrusion Line

Image Detail

1. Far Creative Twin Screw Extruder

The extruder of PVC PVC Crust Foam Board Production Line adopts high efficiency screw & barrel, notched feeding cylinder and is equipped with strong water jacket cooler, which greatly improves its transmission capacity and guarantees high-efficiency extrusion. the gearbox is hardening teeth gearbox with self-lubrication system.

The motor adopts Siemens standard motor and speed controlled by ABB inverter. The control system adopts Siemens PLC control or button control.

2. Die Mould

Spacious flow channel design to guarantee high extrusion capacity and good melt.

Optimized temperature control and flow channel design, precise melt temperature control.

3. Vacuum Calibration platform

The shaping table is made of 304 stainless steel, and the main shaping part is made of materials such as brass, steel or aluminum to reduce wear and chrome plating.

High-precision high-quality water ring vacuum pump ensures a stable vacuum environment. The cooling is realized by a water bath, the cooling and heating are uniform, and the production process is simple and convenient.

4. Cooling bracket

The length of the cooling roller table is 3910mm, using stainless steel rollers

5. Rubber roller tractor

The upper and lower rubber rollers are used for traction, and the clamping method adopts the cylinder clamping action

The lower roller is a driving roller, and the upper roller is a passive roller

6. Cutter

7.Automatic Palletizer
